Garmin GPSMAP® 8416xsv – 16" chartplotter/fishfinder

Garmin GPSMAP® 8416xsv – 16″ touchscreen chartplotter and sonar

The Garmin GPSMAP® 8416xsv is a top-class navigation display combining a large, crystal-clear touchscreen, built-in sonar and full network connectivity. Ideal for professional use, demanding passages and precise fishing.

Key features

• 16″ Full HD IPS touchscreen – very good readability in all light and wide viewing angles.
• Built-in sonar – supports 1 kW traditional CHIRP, CHIRP ClearVü and SideVü. Also compatible with Panoptix™, LiveScope™ and UHD transducers (sold separately).
• Powerful connectivity – Garmin Marine Network, NMEA 2000, NMEA 0183, Wi-Fi, Bluetooth and ANT.
• SmartMode™ – quickly switch between layouts such as sonar, radar or chart view.
• Quickdraw™ Contours – save personal depth maps with 1 ft contours covering up to 2 million acres.
• Waterproof and rugged (IPX7) – reliable in harsh weather.

Specifications

• Display: 16″ Full HD IPS (1920 × 1200 px)
• Dimensions: approx. 38.5 × 26.3 × 7.6 cm
• Weight: approx. 4.4 kg
• Power: 10–32 V DC; typical draw approx. 1.3 A, max. approx. 6.0 A
• Sonar support: CHIRP, ClearVü, SideVü, Panoptix™, UHD
• GNSS: GPS / GLONASS, 10 Hz update
• Connections: Ethernet, HDMI, SD card slots, NMEA 2000/0183, Wi-Fi, Bluetooth, ANT
• Water rating: IPX7
• Mounting: flush, bail or frame
