Description
The Suntrack DUO 24 V / 30 A Battery Charger is a fully automatic, “set-and-forget” solar charger. It’s engineered to quickly and accurately recharge deep cycle batteries using algorithms that maximize their lifespan. Equipped with advanced multi-stage smart charging technology, this charger can remain permanently connected to your battery bank. With multiple input sources, it ensures your batteries are charged whether you’re on the move or the sun is shining on your solar array.
Featuring a state-of-the-art, user-friendly design battery charger. the Suntrack DUO 24 V / 30 A delivers reliable multi-stage, multi-input charging for all types of batteries. It’s suitable for home, boats, RV caravans, 4WDs, commercial vehicles, and other applications.
Technical data
| Manufacturer | WhisperPower |
| Article number | 60111431 |
| Dimensions & weight | |
| Length x width x height, mm (in.) | 242 x 172 x 74 (9.5 x 6.8 x 2.9) |
| Weight, kg (lb.) | 1.85 (4.1) |
| Output rating | |
| Output Current (Maximum) | 30 A |
| Output Voltage | 24 V Nominal |
| Output Power | 930 W |
| Charger dc output- house battery (ch1) | |
| Selectable Battery Type | GEL, AGM, Flooded, Lithium, Program |
| Bulk /Float Voltage Range GEL: | 28.8 / 27.4 Vdc |
| Bulk /Float Voltage Range AGM: | 29.2 / 27.2 Vdc |
| Bulk /Float Voltage Range Flooded: | 28.8 / 26.6 Vdc |
| Bulk /Float Voltage Range Lithium: | 27.8 – 29.2 Vdc |
| Bulk /Float Voltage Range Program: | 27.6 – 29.6 Vdc |
| Restart Voltage (GEL, AGM, Flooded, Program) | 25.0 Vdc |
| Restart Voltage (Lithium) | 26.6 Vdc |
| Charger Current (User Selectable) | 5 / 10 / 20 / 30 A |
| Equalized Voltage (Flooded Battery only) | 31.0 Vdc |
| Equalized Charging Current | 10% of Bulk Current Setting |
| Charging Control | GEL, AGM Flooded, Program Mode: Two or Three Stages Lithium: Three Stages only |
| DC Output Bank | Single |
| Current draw from CH1 with unit ON | < 70 mA |
| Current draw from CH1 with unit OFF | < 200 uA |
| Battery Temperature Setting | Low / Normal / High (automatically overridden with optional BTS) |
| Efficiency | 95% |
| Minimum Operating Voltage | 16.0 Vdc |
| Dc input - solar array/panels (ch2- solar) | |
| Maximum Solar Input Current | 30 A |
| Maximum Solar Input Power: 12VPanel | 500 W (600 W max) |
| Maximum Solar Input Power: 24V Panel | 900 W (1080 W max) |
| Dc input – alternator/ start battery (ch3- alternator/start) | |
| Input voltage | 10.5 – 16.0 Vdc / 21 – 32 Vdc |
| Maximum Input Current (as per max. setting) | 50 A |
| Regulatory compliance | |
| Standards/EMC (North America) | Class B according to FCC part15B and ANSI C63.4 |
| Standards/EMC (European Union) | CE marked for the EMC directive 2004-108-EC Complying with EN55014-1, EN55014-2, EN61000-3-2 and EN61000-3-3 (as equivalent IEC standards series) |
Documents: Datasheet · User manual
